Square D EDB E-frame Bolt-on Miniature Circuit Breakers 60 A 600Y/347 VAC 14 kAIC 3 3 Phase
Mfg #:
EDB36060
BOR #:
1425815
Related Items
Select Options
| Brand | Square D |
| Wire Size | 12 - 2/0 AWG |
| Circuit Breaker Type | Miniature Breaker (Standard) |
| Trip Type | Thermal Magnetic |
| Net Weight | 4 lb |
| Indicator Type | Common |
| Number of Poles | 3 |
| Interrupting Rating | 14 kAIC |
| Frame Type | E Frame |
| Amperage | 60 A |
| Voltage | 600Y/347 VAC |
| Number of Spaces | 3 |
| Number of Phases | 3 Phase |
| Series | EDB E-frame |
| Mounting Type | bolt-on |
| Product Certifications | cULus |
| Poles Description | 3 |
| Trip Range | HTTP,//CISNT06.C076.US.SCHNEIDER-ELECTRIC.COM/PUBS/CIRCUIT20PROTECTION/MOLDED20CASE20CIRCUIT20BREAKERS/012520A20FRAME20EDB-EGB-EJB/515-4.PDF |
| NF/NFOM Panelboards Installation Instructions and User Guide (80043-741) - 80043-741-03 (pdf) | Installation and Instruction Manuals |
|
| Square D NF Circuit Breaker Panelboards Catalog - 1670CT0701 (pdf) | Catalog |
|
| E-Frame, Certificate, UL - 19980918-E84967A (pdf) | Compliance |
|
| PowerPacT: The New Generation of Molded Case Circuit Breakers (MCCB) - brochure - 998-21101950_NAM_PowerPacT (pdf) | Brochure |
|
| E-Frame, Certificate, UL - 20110328-E84905 (pdf) | Compliance |
|
| Powerbus Busway Brochure - 5600BR1201 (pdf) | Brochure |
|
| Square D Specification Sheet | Specification Sheet |
|
| E-Frame, Certificate, UL - 20150724-E84905 (pdf) | Compliance |
|
