Square D QO™ QHB Bolt-on Miniature Circuit Breakers 25 A 240 VAC 65 kAIC 3 Pole
Image shown may be a representative image and may not reflect the exact product
| Brand | Square D |
| Circuit Breaker Type | Miniature Breaker (Standard) |
| Net Weight | 0.390 kg |
| Number of Poles | 3 Pole |
| Interrupting Rating | 65 kAIC |
| Amperage | 25 A |
| Voltage | 240 VAC |
| Series | QO™ QHB |
| Mounting Type | Bolt-on |
| A Guide to Your Square D Electrical Distribution System - Brochure - 0102BR0201 (pdf) | Brochure |
|
| Square D QO and QOB Miniature Circuit Breakers Catalog - 0730CT9801 (pdf) | Catalog |
|
| Panelboards: Section 9 - Digest 179 (2024) - Panelboards-Lighting-Digest-Catalog-0100CT2401-SEC-09 (pdf) | Catalog |
|
| NQ/NQM Panelboards and QONQ Load Centers User Guide - Installation Instructions (80043-712) - 80043-712-06_Instruction+Bulletin_NQ-NQM+Panelboards+and+QONQ+Load+Centers (pdf) | Installation and Instruction Manuals |
|
| Square D Combination AFCI Circuit Breakers Brochure - 0700BR1202 (pdf) | Brochure |
|
| Certificate | Compliance |
|
