Square D JLA J Frame Molded Case Circuit Breakers 175 A 600 VAC 25 kAIC 3 Pole
Molded Case Circuit Breakers
- JLA Series
- J Frame
| Brand | Square D |
| Voltage | 600 VAC |
| Frame Type | L Frame |
| Interrupting Rating | 25 kAIC |
| Trip Type | Fixed Thermal and Magnetic Trip |
| Amperage | 175 A |
| Circuit Breaker Type | Molded Case Breaker |
| Number of Poles | 3 Pole |
| Net Weight | 2.4 kg |
| Certificate 2 | Compliance |
|
| PowerPacT with MicroLogic Brochure - 0600BR1101 (pdf) | Brochure |
|
| Certificate 3 | Compliance |
|
| Field Testing and Maintenance Guide Installation - 48049-900-02 (pdf) | Installation and Instruction Manuals |
|
| PowerPacT H-, J-, and L-Frame Circuit Breakers Catalog - 0611CT1001 (pdf) | Catalog |
|
| Certificate 1 | Compliance |
|
| Low Voltage Circuit Breakers for OEM Applications Brochure - 0106BR9806 (pdf) | Brochure |
|
