Square D PowerPacT™ HJA Shunt-trip Molded Case Circuit Breakers 35 A 600 VAC 25 kAIC 3 Pole
Mfg #:
HJA36035SA
BOR #:
3567504
| Brand | Square D |
| Voltage | 600 VAC |
| Frame Type | H Frame |
| Interrupting Rating | 25 kAIC |
| Trip Type | Thermal Magnetic |
| Amperage | 35 A |
| Circuit Breaker Type | Molded Case Breaker |
| Number of Poles | 3 Pole |
| Net Weight | 2.2 kg |
| PowerPacT H-, J-, and L-Frame Circuit Breakers Catalog - 0611CT1001 (pdf) | Catalog |
|
| Undervoltage Trip (MN) and Shunt Trip (MX) Installation for PowerPacT H-, J-, and L-Frame and TeSys GV5/GV6 Circuit Breakers - 48940-229-01 (pdf) | Installation and Instruction Manuals |
|
| Certificate 2 | Compliance |
|
| Low Voltage Circuit Breakers for OEM Applications Brochure - 0106BR9806 (pdf) | Brochure |
|
| Certificate 1 | Compliance |
|
Installing YA060HD Compression Lug Kit for PowerPact H-Frame Breakers | Schneider Electric Support
Tutorial for installing and wiring the YA060HD Compression Lug Kit for PowerPact H-Frame Molded ...
