Square D PowerPacT™ HLA Molded Case Industrial Circuit Breakers 100-100 A 600 VAC 50 kAIC 3 Pole 3 Phase
Mfg #:
HLA36100
BOR #:
1684341
PowerPact™ Molded Case Industrial Circuit Breakers
- HLA Series
Related Items
Select Options
| Brand | Square D |
| Includes | Auxiliary Switch |
| Mounting Type | I-Line bracket) |
| Voltage | 600 VAC |
| Frame Type | H Frame |
| Interrupting Rating | 50 kAIC |
| Trip Range | 900 - 1700 A |
| Number of Phases | 3 Phase |
| Wire Size | 14 - 3/0 AWG |
| Trip Type | Fixed Thermal and Adjustable Magnetic Trip |
| Amperage | 100-100 A |
| Circuit Breaker Type | Molded Case Breaker |
| Indicator Type | Common Trip |
| Number of Poles | 3 Pole |
| Net Weight | 2.2 kg |
| Product Certifications | UL ,, CSA ,, NOM |
| Wire Stripping Length | 16 mm |
| [Ith] Conventional Free Air Thermal Current | 100 A |
| Magnetic Tripping Current | 1700-1700 A |
| Square D Specification Sheet | Specification Sheet |
|
| Square D I-Line Panelboards and Switchboards Brochure - 2100BR1301 (pdf) | Brochure |
|
| Certificate 1 | Compliance |
|
| Low Voltage Circuit Breakers for OEM Applications Brochure - 0106BR9806 (pdf) | Brochure |
|
| PowerPacT with MicroLogic Brochure - 0600BR1101 (pdf) | Brochure |
|
| PowerPacT H-, J-, and L-Frame Circuit Breakers Catalog - 0611CT1001 (pdf) | Catalog |
|
Installing Terminal Nut Kit on PowerPact™ H & J-Frame Breakers | Schneider Electric Support
Tutorial for installing the Terminal Nut Kit on PowerPact™ H & J-Frame Molded Case Circuit Breakers...
