Square D PowerPacT™ JDA Molded Case Industrial Circuit Breakers 225 A 600 VAC 14 kAIC 2 Pole
PowerPact™ Molded Case Industrial Circuit Breakers
- JDA Series
| Brand | Square D |
| Voltage | 600 VAC |
| Frame Type | J Frame |
| Interrupting Rating | 14 kAIC |
| Trip Type | Fixed Thermal and Magnetic Trip |
| Amperage | 225 A |
| Circuit Breaker Type | Molded Case Breaker |
| Number of Poles | 2 Pole |
| Net Weight | 2.4 kg |
| Low Voltage Circuit Breakers for OEM Applications Brochure - 0106BR9806 (pdf) | Brochure |
|
| Certificate | Compliance |
|
| PowerPacT with MicroLogic Brochure - 0600BR1101 (pdf) | Brochure |
|
| PowerPacT H-, J-, and L-Frame Circuit Breakers Catalog - 0611CT1001 (pdf) | Catalog |
|
Installing S29451 Overcurrent Trip Actuator on PowerPact H & J Breakers | Schneider Electric Support
Tutorial for installing the S29451 SDE Overcurrent Trip Switch Adapter on PowerPact H- or J-Frame...
Installing S29450 Auxiliary-Alarm Switch on PowerPact H & J Breakers | Schneider Electric Support
Tutorial for installing the S29450 Auxiliary / Alarm Switch on PowerPact H- or J-Frame Molded Case...
AL175JD vs. AL250JD: Unraveling the Differences in Current Transformer Lug Kits | Schneider Electric
In this tutorial video, we dive into the details of the AL175JD and AL250JD current transformer lug...
Installing S29313 Toggle Extension on H & J Frame Circuit Breakers | Schneider Electric Support
Tutorial for installing the handle toggle extension on an PowerPact H-frame or J-frame molded case...
Using Open Door Shaft Operator on PowerPact B, H, J, L-Frame Breakers | Schneider Electric Support
Tutorial for installing and using the LV426937 Open Door Shaft Operator for PowerPact™ B-, H-, J-,...
